Professional Single Row Double Row Four Row Cylinder Roller Bearing NF200 Series

Brand Name : Solarich

Model Number : N series, NF200

Certification : ISO9001

Place of Origin : China

MOQ : 1

Price : Customized

Payment Terms : L/C, T/T, D/P, Western Union

Supply Ability : 1000000

Delivery Time : 10-15days

Packaging Details : Original Package, Tube&Customized, as your requests, Industrial Package

Number of row : single row , double row , four row

Precision rating : P0 P6 P5 P4 P2, P6, P0, P4, P5

Type : Roller

Structure : Cylindrical

Seals type : Open, ZZ 2RS OPEN, RS, ZZ, 2RS

Material : Chrome Steel, bearing steel, stainless steel, AISI440C, Gcr15

Service : OEM Service.Design Service, OEM Customized Services, Customization & OEM Service, ODM, OEM

Application : Automotive, Machinery, Taper Roller Bearing, etc, cars

Cage : Steel Cage, e, mb, cc, nylon. Copper alloy

Outside diameter : 47 - 225 mm, 51.99 - 52 mm, 5 - 3000 mm, 160 - 160.01 mm, 15 - 986 mm

Clearance : C3, C4, C2, CO, C1 C2 0 C3 C4 C5

Vibration : V1 V2 V3 V4, Z1V1 Z2V2 Z3V3 Z4V4

Feature : Long Life, durable, 2.9921x5.1969x1.5354"

Package : Original Package, Tube&Customized, as your requests, Industrial Package

Stock : 50000pcs, Ready Goods, 200 pieces, large, Inch Bearing

Contact Now

Cylindrical roller bearing

Cylindrical roller bearings with inner or outer rings without fenders, whose inner and outer rings can move relative to each other in axial direction, can be used as free-end bearings. Cylindrical roller bearings with double rim on one side of the inner and outer rings and a single rim on the other side of the ring can withstand a certain degree of axial load in one direction. Generally used steel plate stamping cage, or copper alloy car solid cage. But some use nylon forming cages.

Cylindrical roller and raceway for line contact bearings. Large load capacity, mainly bearing radial load. The friction between the rolling body and the rim of the ring is small, suitable for high-speed rotation. According to whether the ring has a rim or not, it can be divided into NU, NJ, NUP, N, NF and other single-row cylindrical roller bearings, and NNU, NN and other double-row cylindrical roller bearings. The bearing is a detachable structure with inner ring and outer ring.

Professional Single Row Double Row Four Row Cylinder Roller Bearing NF200 SeriesProfessional Single Row Double Row Four Row Cylinder Roller Bearing NF200 SeriesProfessional Single Row Double Row Four Row Cylinder Roller Bearing NF200 SeriesProfessional Single Row Double Row Four Row Cylinder Roller Bearing NF200 SeriesProfessional Single Row Double Row Four Row Cylinder Roller Bearing NF200 Series

Bearing No. Principal Dimensions(mm) Basic Load Ratings(KN) Limited Speed(rpm) Weight (kg)
d D B rs min rs1 min Dynamic(Cr) Static(Cor) Grease Oil
NF204E 20 47 14 1 0.6 17 14 17000 20000 0.109
NF205E 25 52 15 1 0.6 28 27 11000 14000 0.148
NF206E 30 62 16 1 0.6 36 36 8500 11000 0.22
NF207E 35 72 17 1.1 0.6 47 48 7500 9500 0.344
NF208E 40 80 18 1.1 1.1 52 53 7000 9000 0.39
NF209E 45 85 19 1.1 1.1 59 64 6300 8000 0.52
NF210E 50 90 20 1.1 1.1 61 69 6000 7500 0.56
NF211E 55 100 21 1.5 1.1 80 96 5300 6700 0.62
NF212E 60 110 22 1.5 1.5 90 102 5000 6300 0.84
NF213E 65 120 23 1.5 1.5 102 118 4500 5600 1.05
NF214E 70 125 24 1.5 1.5 112 135 4300 5300 1.29
NF215E 75 130 25 1.5 1.5 125 155 4000 5000 1.45
NF216E 80 140 26 2 2 132 165 3800 4800 1.74
NF217E 85 150 28 2 2 158 192 3600 4500 2.08
NF218E 90 160 30 2 2 170 203 3400 4300 2.5
NF219E 95 170 32 2.1 2.1 192 214 3200 4000 2.8
NF220E 100 180 34 2.1 2.1 208 226 3000 3800 3.14
NF221E 105 190 36 2.1 2.1 224 238 2800 3600 4
NF222E 110 200 38 2.1 2.1 239 342 2600 3400 5.11
NF224E 120 215 40 2.1 2.1 247 249 2200 3000 6.32
NF226E 130 230 40 2.1 2.1 358 372 2000 2800 7.38
NF228E 140 250 42 2.4 2.4 302 415 1800 2400 9.01
